Synthesis of 6-aryl-7-arylazo-4-(N-substituted aminomethyl)-2H-thiazolo-[3, 2-a]-1, 3, 5-triazino-2-thiones as Antiviral Agents

2-amino-4-aryl thiazole was diazotised with different aromatic amines to give 2-amino-4-aryl-5-arylazo thiazoles. These compounds were refluxed with ammonium thiocyanate and chloroacetyl chloride in acetone to afford N1-chloroacetyl-N3-(4-aryl-5-arylazothiazol-2-yl)-thioureas. These thioureas were cyclized in presence of POCl3 and PCl5 to give 6-aryl-7-arylazo-4-chloromethyl-2H-thiazolo-[3, 2-a]-1, 3, 5-triazino-2-thiones. These compounds were reacted with secondary amines in methanol to give title compounds 6-aryl-7-arylazo-4-(N-substituted aminomethyl)-2H-thiazolo-[3,2-a-]1,3,5-triazino-2-thiones.Antiviral nature of these compounds was studied against Ranikhet Disease Virus (RDV), Vaccinia Virus (VV) and Sunnhemp Rosette Virus (SRV). Some of these compounds have been found to be active against RDV and Vaccinia Virus.

Illustrations explain the paper; they do not show study data.

AI-generated illustration

↗ Enlarge

Study overviewClose ×

AI-generated conceptual illustration (thiazolo-triazino-thione chemical molecules and viral particles). It explains the idea and does not show study data.

Open full-size image ↗

Introduction

Triazine derivatives have been reported to exhibit pronounced antiviral activity against various strains of viruses [1][2][3] . 2-amino-4-arylamino-5-triazines have been found to possess promising antiviral activity [4] . Recently some substituted triazino-2-thiones have been found to be associated with antiviral activity against RDV. These varied Scheme observations led the author to synthesize twelve new title compounds and to study their pharmacological action. Methodology 2-amino-4-aryl thiazole (1) was diazotised with different aromatic amines to give compounds (2-4). These compounds were refluxed with amonium thiocyanate and chloroacetyl chloride in acetone to afford N 1 -chloroacetyl-N 3 -(4-aryl-5-arylazo-thiazol-2-yl)-thioureas (5-7). These thioureas were cyclized in presence of POCl3 and PCl5 to give 6-aryl-7-arylazo-4-chloromethyl-2H-thiazolo-[3, 2-a]-1, 3, 5-triazino-2-thiones (8-10). These compounds were reacted with secondary amines in methanol to give title compounds (11-22). Melting points of the compounds were taken in a sulphuric acid bath in open capillaries. Structures of final compounds were confirmed by IR, PMR spectra and TLC. 2-amino-4-aryl thiazole (1) was prepared by the known method [5] . This thiazole was converted into 2-amino-4-aryl-5-arylazothiazoles (2-4) by known procedure [6] .

N 1 -chloroacetyl-N 3 -(4-aryl-5-arylazo thiazol-2-yl)thioureas (5-7)

To a mixture of ammonium thiocyanate (0.06 mole) and chloroacetylchloride (0.06 mole) in acetone (160 ml) heated under reflux for 30 min was added 2-amino-4-aryl-5arylazo-thiazoles (2-4) and the reaction mixture was further refluxed for 3-4 hrs. After this the reaction mixture was poured into excess water. The desired thiourea thus precipitated was filtered, washed and recrystallized from DMF-ethanol mixture (1:1). Characterisation data of these compounds are as follows: A mixture of 8-10 (0.01 mole) and an appropriate secondary amine (0.01 mole) in methanol (25 ml) was refluxed on water bath for 6-8 hrs. After that the reaction mixture was poured on ice cooled water. The solid thus separated was filtered, washed with water and recrystallized from methanol. All the compounds (11-22)

Antiviral activity against rdv

Compounds were tested against RDV in a stationary culture of minced chorioallantoic membrane of chick embryo. The strain of the Ranikhet Disease Virus was the same as employed by Babber and Dhar [7] . Chorioallantoic membrane (CAM) of 10 days old chick embryos were taken and the culture prepared according to the method of Babbar [8, 9] . The soluble compounds were dissolved in a nutrient fluid and the insoluble compounds were suspended in it in the presence of Tween 80 and the pH adjusted to 7.2 before sterilization. The solutions were then sterilized by autoclaving at 15 lbs pressure for 15 min. Two fold serial dilutions were then made and 1 ml of each dilution added to each of the test tubes containing the CAM culture. The dilution of a compound causing toxic symptoms in 50% of the CAM culture was taken as the end point. The highest nontoxic dose was given to each culture along with the virus (0.64 HA units/ml). Virus multiplication was measured by the haem agglutination (HA) titre (mean of log2) of the culture collected after 48 hrs of incubation at 37 °C. Inhibition in virus multiplication was obtained by subtracting this titre from that of the control. The mean difference (d) of 2 log2 HA units is significant at 50% or more than 50% level.

Antiviral activity against vaccinia virus

All the eighteen compounds were also tested [10] against Vaccinia Virus on chick embryo fibroblast monolayers. 0.05 mg/ml compound were given along with Vaccinia virus (50 p/ml) and incubated at 37 °C for 72 hrs. After 72 hrs the monolayers were strained and the numbers of plaques/monolayers were counted. The activity was calculated by the formula C-T/C×100.

Antiviral activity against sunnhemp rosette virus (srv)

The culture of Sunnhemp Rosette Virus was maintained by successive host inoculation (Cyamopsis tetragonoloba plants). The procedure of Mukherjee et al [11] was followed for antiviral testing.

Results and discussion

It is apparent from table-2 that compounds 16 and 22 exhibited 65% and 60% inhibition respectively against RDV. Thus insertion of N-methyl piperazino and morpholino groups in compounds enhances the antiviral activity of compounds. Further compounds 11, 14 and 17 have been found to be toxic. Remaining compounds showed varying degree of antiviral activity ranging from 0 to 40%. The order of antiviral activity of various values of R was found to be nitro chloro H. The results of the antiviral activity against Vaccinia Virus given in table-2 shows that only compound 13 has showed pronounced antiviral activity, whereas compound no. 16 was found to possess mild antiviral activity (50%). These results indicate that probably substitution by piperidino and N-methyl piperazino group may be responsible for the antiviral nature of the compound. The results of activity against SRV show that all the compounds were found to be toxic in nature and possess no antiviral effect. However, compound 12, 14, 21 and 22 were found to possess comparatively less toxic effects.

1. Fawzy A Attaby et al. Phosphorus, Sulphur and Silicon and the Related Elements. 2007, 182
2. Rusinov VL, Egorov LN, Chuphakin ON, Belanov EF, Bormotov NI, Serova OA. Pharmaceutical Chemistry Journal. 2012; 45:655-659.
3. Pandey VK, Tusi Z, Tandon M, Joshi MN, Bajpai SK, NOPR, 2003, 2583-2588.
4. Pandey VK, Sarah Tusi, Tusi Z, Joshi M. Acta Pharmaceutica. 2004; 54:101-12
5. Dodson RM, King LC. J Am. Chem. Soc. 1945; 67:2242
6. Garg HG, Sharma RA, J Pharm. Sci. 1970; 59:348-53.
7. Babbar OP, Dhar MM. J Sci. Ind. Res. 1956; 15c:249.
8. Babbar OP. J. Sci. Ind. Res. 1961; 20c:216.
9. Babbar OP. J. Sci. Ind. Res. 1961; 20c:232.
10. Babbar OP, Chowdhury BL, Singh MP, Khan SK, Bajpai S. Indian J Exp. Biol. 1970; 8:204-12.
11. Mukherjee DD, Shukla SK, Verma HN, Awasthi LP. Acta Pharm Jugoslav. 1981; 31:151.
